Electric Mini skid steer loader

SSQ ECO

Electric, compact, powerful

LIFTING

450Kg

WITH COUNTERWEIGHTS

ENGINE POWER

5,7Kw

PERMANENT MAGNETS

HYDRAULIC FLOW RATE

18,5L/min

HYDROSTATIC PUMP

The powerful and compact electric mini loader that respects the environment. Zero emissions for cleaner air and eco-friendly batteries with enhanced safety, free from liquid leaks.
Charging time is about 7 hours, while the operating range at average workload is 8 hours.

POWER

traction battery

The powerful electric motor with two permanent magnets is very quiet, and the battery can provide up to 7 hours of autonomy depending on usage intensity. SSQ ECO is available with a 36-volt electrolyte traction battery with a nominal capacity of 240 Ah, offering excellent autonomy even under heavy use, a lightweight design, and an extended service life.

These features make the SSQ ECO the most proven electric mini loader on the market today.

video

SSQ ECO in motion

FEATURES

DESIGNED TO BE SIMPLE

TECHNICAL DATA SHEET

ALL THE INFORMATION YOU NEED

DATA	SPECIFICATIONS
Engine	Electric, 2 permanent magnets
Battery type	Traction battery
Nominal voltage (V) – Battery capacity (Ah)	36 – 240
Power Kw	5,7
Hydraulic flow rate l/min	18,5
“Forklift”	4.00-8
Side protections	Standard
Lifting capacity Kg	450 (with counterweights)
Traction capacity Kg	390 (with counterweights)
Tear-off force Kg	400
Dimensions ( L mm x W mm x H mm)	1525x740x1250
Weight Kg	850
